Capability · heavy weldments

Serial weldments, welded, machined and NDT-documented, one contract

You send a drawing. You receive a weldment machined after welding, with material certificates, the dimensional report and the NDT protocol, under one PO. In-house to 10 t per EN ISO 3834-2. To 64 t x 45 m via a certified partner under EN 1090-2 EXC2. Stratosteel owns the outcome.

Send a drawing

What arrives at your dock

The weldment, machined after welding where the drawing requires it
EN 10204 3.1 certificates for input material
Dimensional report, CMM trace on critical features
NDT protocol: UT, MT, PT per EN, scope agreed before welding
Welding documentation per EN ISO 3834-2 or EN 1090-2 scope

Part families

Machine frames, booms and attachments. Structures for crushing and screening plant. Hydromechanical structures: radial and flat gates, stop logs, liners, draft tube and penstock sections, segmented for transport. Base frames and housings, machined after welding.

Proof

6 years of serial weldments for an Austrian forestry equipment OEM. Same customer, same program, running. Name disclosed under NDA. Check the proof page.

Materials

S355, S690QL, S960QL high-strength steels, HARDOX, 42CrMo4, with full NDT documentation. Standards EN ISO 3834-2, EN 1090-2.

Envelope

In-house	up to 10 t, EN ISO 3834-2
Via certified partner	up to 64 t × 45 m
Structural class	EN 1090-2 EXC2
Machining after welding	integrated, workpiece up to 50 t
NDT	UT, MT, PT per EN
Documentation	EN 10204 3.1, dimensional report, NDT protocol

Real parts, real proof

Certified heavy weld shop interior — Certified weld shop

Welded, machined and assembled gear housing — Welded + machined

Welded chassis frame structure, shot-blast finish — Welded chassis structure

Welded, machined, inspected, one contract.

Heavy weldments usually need machining and full NDT. We carry all of it and the single point of responsibility.

Heavy machining

Machine the weldment, envelope 9 x 3 x 2.5 m, form-position 0.03 to 0.05 mm.

Quality & NDT

EN 10204 3.1, CMM dimensional report, NDT protocol per EN.

Heavy equipment + forestry

6 years of serial weldments for one OEM.

Straight answers

Weldment questions.

What arrives with a weldment from Stratosteel?

The weldment, machined after welding where the drawing requires it, with EN 10204 3.1 certificates for input material, a dimensional report and an NDT protocol (UT, MT, PT per EN). One contract covers all of it.

What weldment sizes and classes can you supply?

In-house to 10 t per EN ISO 3834-2. To 64 t x 45 m via a certified partner under EN 1090-2 EXC2. Materials include S355, S690QL, S960QL, HARDOX and 42CrMo4.

What is your serial weldment track record?

6 years of serial weldments for an Austrian forestry equipment OEM, same customer, same program, running. Name disclosed under NDA. To test us, send 1 to 3 drawings to rfq@stratosteel.com, firm quote in 3 to 7 working days.
